HUD & Gab Windows

Gab Windows are text windows that you can dynamically put on the game screen, whether they are part of the game’s HUD or a speech bubble above the player or any other NPC. As they interpret text codes (\C, \V, …), it’s super simple to do something with Icons and Variables!

Features

  • You can add as many Gab Windows as you want to your Game to create a HUD
  • A Gab Window can be used as part of your HUD or as a speech bubble above your hero or an NPC
  • Gab Windows understand Message Codes. You can easily choose a Text Color, draw Icons and display Variables!
  • Auto Expire: A Gab Window will automatically close itself after x frames (speech bubble) or stay until you remove it using a plugin command (HUD)
  • A Gab Window will be less opaque when it covers the player
  • You can override the background type (window, dimmed, transparent) and the window skin for each Gab Window
  • Open & close animations are played
  • Gab Windows are persisted in your save game

JavaScript

MZ users can use Plugin Commands to add or remove Gab Windows, but they can also use JavaScript. MV users must use JavaScript to use this plugin.

Add Gab Window

$gameScreen.addGabWindow(id, {
  align: ?,
  anchor: ?,
  autoExpire: ?,
  backgroundType: ?,
  backOpacity: ?,
  eventId: ?,
  fontSize: ?,
  height: ?,
  hidden: ?,
  target: ?,
  text: ?,
  textPadding: ?,
  width: ?,
  windowskin: ?,
  x: ?,
  y: ?,
})

Example

$gameScreen.addGabWindow('helloWorld', {
  align: 'center',
  autoExpire: 60,
  eventId: 0,
  text: '\\C[1]Hello World!',
})

Required Arguments

Identifier

You must pass a unique identifier. This helps you to refer to your Gab Window later. It can be any string.

Optional Parameters

Parameters in { } are optional! When not given, the plugin will use a default value. Parameters are a key-pair value, e.g., use {align: ‚left‘} to set text alignment to left.

Text

Text to show. You may use Text Codes (\C, \V, …).

text: '\\C[1]Hello World!',

Due to the nature of JavaScript, you need to escape the backslash symbol. Use \\V[1] instead of \V[1].

Positioning

You have several options to choose from.

When you want to add your Gab Window as part of your game’s HUD, you can simply pass x and y coordinates.

x: 200,
y: 200,

When you want to bind your Gab Window to the player, pass eventId: 0 as a parameter.

eventId: 0,

When you want to bind your Gab Window to an Event, pass an event ID!

eventId: 1 or any other number

You can also use „target“ instead of eventId. „Target“ is a more advanced option. You can choose from:

  • Follower 1, Follower 2, Follower 3, …
  • Boat, Ship, Airship,
  • Event 1, Event 2, …
  • Player

Example:

target: 'Follower 1'
Width

The plugin guesses the width automatically depending on the given text.

Alternatively, you may pass a positive number here.

Height

The plugin guesses the height automatically depending on the given text.

Alternatively, you may pass a height value:

height: 100,

All Parameters

alignchoose from ‚left‘, ‚right‘, ‚center‘
anchor{ x: number from 0 to 1, y: number from 0 to 1}
Example: { x: 0.5, y: 1.0 }
Default: { x: 0.5, y: 1.0 } when bound to a character, { x: 0, y: 0 } otherwise
autoExpirewhen given, number of frames until this gab window closes itself automatically
Default: Window stays opened until closed by plugin command
backgroundTypechoose from
0 (default window)
1 (dimmed background)
2 (transparent)
Default: 0
backOpacitynumber 0 <= x <= 255
eventId– when 0: Gab Window positions above the Player
– when any positive number: Gab Window positions above Event with given ID
Default: disabled
fontSizenumber
heightheight in pixels
When left out, the plugin will calculate the height automatically for you
hiddentrue / false
Default: false
paddingwindow padding
targetChoose from:
– follower 1, follower 2, follower 3, …
– event 1, event 2, event 3, …
– boat
– ship
– airship
– player
Example: ‚follower 1‘
Default: not used
See also: eventId
texttext to show. You may use Text Codes (\C, \V, …)
textPaddingnumber
widthwidth in pixels
When left out, the plugin will calculate the width automatically for you
windowskinname of an image file in /img/system/ (exluding .png)
Example: 'Window2'
Default: default window skin
xposition (can be left out when Event ID is passed)
yposition (can be left out when Event ID is passed)

Move Gab Window

$gameScreen.moveGabWindow(id, x, y)

Change Text

$gameScreen.gabWindowChangeText(id, text)

Change Gab Window

$gameScreen.changeGabWindow(id, { ... })

You may pass the same parameters as for the method $gameScreen.addGabWindow.

Remove Gab Window(s)

$gameScreen.removeGabWindow(id)
OR
$gameScreen.removeAllGabWindows()

Show/Hide Gab Window(s)

You can temporarily hide and show Gab Windows.

$gameScreen.hideGabWindow(id)
$gameScreen.hideAllGabWindows()
$gameScreen.showGabWindow(id)
$gameScreen.showAllGabWindows()

Map Notetags

You can put this Notetag to any map to disable Gab Windows entirely.

<No Gab Windows>

Download

Download (right-click, save as…)
